We use the examples from JHipster in order to show how to do it with an editor. Note that you don’t need to capitalize type names ( except for composed names like BigDecimal, JHipster-UML capitalizes names).
We have the attributes publicationDate and price set with the types BigDecimal and LocalDate we created as DataType. Here is an example of a properly created class for JHipster. You can look at the tables with all the types supported by JHipster and the validations you can use for each here. To have JHipster supported types like “BigDecimal”, “LocalDate”…, you can create a PrimitiveType or a DataType for it. An attribute must have a type supported by JHipster, otherwise it won’t work. The class diagram should modelize the entities of your JHipster application domain, thus you have restrictions, you have to follow the methodology.Įach entity is represented by a class, its fields are the class’ attributes. To use JHipster-UML, you need a class diagram exported in XMI and JHipster-UML will parse it to create your entities. Otherwise, using v2.0.0+ is the choice for v3.0.0+ of the generator.
#Modelio vs uml designer generator
If you’re using the generator before v3.0.0, then you must use JHipster UML v1.6.5 (latest patch release). JHipster UML is a tool that can be used with the JHipster’s generator. Git clone :jhipster/jhipster-uml.git for SSH If you want the ‘bleeding edge’ (almost perfectly safe to use) version, you can clone our git repo from our GitHub project: You might want to use Powershell or another shell when using JHipster UML (or JHipster). The JHipster generator’s questions (from InquirerJS) could not work (the user is stuck when answering the questions). The link provides a solution to fix that if such a thing happens.įinally, an issue has been reported from a Windows user using Git Bash. This link may help if you encounter an issue on Windows.Īnother issue that can be encountered on Windows is this one.
#Modelio vs uml designer install
Please note that using JHipster-UML (or JHipster) might be troublesome (one has to install some tools to really be able to use the Node environment without any issue). Pull requests are welcome, but the commits must be ‘atomic’ to really be understandable.One posted issue must only have one problem (or one demand/question).When submitting anything, you must be as precise as possible: Please use our project for submitting issues and Pull Requests: JHipster-UML is available on GitHub, and follows the same contributing guidelines as JHipster. Here is a list of the editors we support: JHipster-UML is an alternative to the usual Q&A as it offers you the possibility to use a UML editor to create a diagram that will be parsed by JHipster-UML. If you like this project, don’t forget to give us a star on GitHub!
The JHipster-UML project is available on GitHub, it is an Open Source project like JHipster (Apache 2.0 licence). The idea is that it is much easier to manage relationships using a visual tool than with the classical Yeoman questions and answers. JHipster-UML is a JHipster sub-project that can be used as a replacement to using the entity sub-generator. Instead, we suggest you use the JDL export feature of this project to export your XMI files to a JDL file that you can use and make models of your entities with JDL Studio. Please note that this project is deprecated and shouldn’t be used anymore. Improve this page JHipster-UML to " JHipster-UML"
